Triumph Sprint ST User Manual

73
Maintenance and Adjustment
Operation Description Odometer Reading in Miles (Kms) or Time Period, whichever comes first
First
Service
A Service B Service C Service D Service
Every 500
(800)
1 month
6,000
(10,000)
1 year
12 , 0 0 0
(20,000)
2 years
18,000
(30,000)
3 years
24,000
(40,000)
4 years
Engine and oil cooler - check for leaks Day
•••••
Engine oil - change -
•••••
Engine oil filter - change -
•••••
Valve clearances - check/adjust -
••
Air cleaner - change -
••
Autoscan - carry out a full Autoscan using the Triumph diagnostic
tool
-
•••
Engine ECM - check for stored DTCs
••
ABS ECM - check for stored DTCs
•••••
Spark plugs - check -
••
Spark plugs - change -
••
Throttle bodies - balance -
••••
Throttle cables - check/adjust Day
•••••
Cooling system - check for leaks, chafing etc. Day
•••••
Coolant level - check/adjust Day
•• •
Coolant - change -
••
Fuel system - check for leaks, chafing etc. Day
•••••
Lights, instruments and electrical systems - check Day
•••••
Steering - check for free operation Day
•••••
Steering head bearings - check/adjust -
•••••
Steering head bearings - lubricate -
••
Forks - check for leaks/smooth operation Day
•••••
Fork oil - change -
•

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
