Trojan TR 1000 - Hardware and Tools List; Assembly Preparation

7
TR 1000 - T
HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be provided for assembly.
Main Frame
1 PC
#5 Allen Key 5 mm
1 PC
Plug Cable
1 PC
Bolt M8 x 55
6 PCS
Wrench W/Screw Driver
S=13\14\15 mm
1 PC
Lock washer 8
1 PC
Bolt ST4.2 x 19
4 PCS
Bolt M8 x 16
4 PCS
#6 Allen Key 6 mm
1 PC
MP3 Wire
1 PC
Safety Key
1 PC
Oil Bottle
1 PC
Left Base Cover
1 PC
Right Base Cover
1 PC
1
61
73
76
12
64
74
31
65
88
57
51
89
Right Base Cover
1 PC
74
