TR 1000 - T
PARTS LIST
No. Description Qty
1 Main Frame 1
2 Base Frame 1
3 Left Upright Tube 1
4 Right Upright Tube 1
5 Incline Bracket 1
6 Computer Bracket 1
7 Speaker Net Cloth 1
8 Speaker Net 1
9 Front Roller 1
10 Rear Roller 1
11 Cylinder 1
12 #5 Allen Key 1
13 Metal Plate 4
14 Dc Motor 1
15 Running Board 1
16 Side Rails Buckle 2
17 Bolt M10 x 45 4
18 Motor Cover 1
19 Motor Front Cover 1
20 Side Rails 1 2
21 Side Rails 2 2
22 Right End Cap 1
23 Left End Cap 1
24 Motor Belt 1
25 Left Handlebar 1
26 Running Belt 1
27 Foot Pad 4
28 Ring Wire Protector A 2
29 Wheel 2
No. Description Qty
30 Wire Socket 1
31 Power Cable 1
32 Power Switch 1
33 Flat Washer 1
34 Bolt ST4.2 x 13 25
35 Computer Up Cover 1
36 Computer Bottom Cover 1
37 Cushion Post 2
38 Computer Control Board 1
39 Bolt ST4.2 x 9 2
40 Motor Control Board 1
41 Computer Bottom Wire 1
42 Computer Up Wire 1
43 Left Wheel Cover 1
44 Right Wheel Cover 1
45 Bolt M8 x 90 1
46 Bolt M8 x 25 1
47 Bolt M8 x 32 4
48 Right Handlebar 1
49 Bolt M8 x 65 2
50 Sleeve 8
51 Bolt M8 x 16 4
52 Incline Motor 1
53 Bolt M8 x 55 8
54 Wheel 2
55 Flat Washer 5
56 Spring Washer 8
57 Bolt M5 x 8 6
58 Nut 12
