16 D1
+
PERSONAL DUST MONITOR
Technical specification
XD1+_User manual_P5650.1600_Rev A
Sensing technology OPC light-scatter photometer
Particulate measurement 0.1 µm to 10 µm (PM1, PM2.5, PM4.25, PM10)
Particle count accuracy ±10%
Operating temperature
Optimum performance
Maximum performance
10 °C to 40 °C
-10 °C to 50 °C
Humidity
Optimum performance
Maximum performance
20% - 80% RH, non-condensing
0% - 95% RH, non-condensing
Housing material PC/ABS polymer housing
Ingress protection Main enclosure: IPX4
Particle flow path: IP4X
Weight 170 g
Data connections USB-C connector (charging and data transfer)
Bluetooth LE 5.3
Connectivity
BreatheLITE PC application
BreatheMOBILE application
User options STEL and TWA alarm setpoints
Latching alarms
Particulate measurement
Operating range Up to ~150 mg/m³
Particulate density range 0.8 g/ml to 8.0 g/ml (default 1.65 g/ml)
Units of measurement µg/m³ – Logged on device
µg/m³ or mg/m³ – BreatheLITE application
Sampling interval Custom 1 second intervals (default 10 seconds)
Flow rate 0.1 L/min
User interface/alarms Visual icon illumination (STEL, TWA, battery indication)
Audible (85 dB)
Vibration alert
Self-test Sensor hardware, circuitry and battery test on activation
‘Push to test’ during operation
Response test Custom particle compliance test
Battery capacity 8.2 Wh lithium ion
Battery run time 16 hours (full health at ambient)
Charging temperature limits 0 °C to 45 °C
Charging time 0% to 90%: 2 hours
0% to 100%: 3 hours
Max. charge current 1.5 A
Memory capacity 1 GB (6 months data logging at 10 second intervals)
Product fixing/body mounting Personal mounting clip, Klick Fast stud options
Certification UKCA and CE compliant
