8.2 Product dimensions
64 mm
(2.5 in)
25 mm
(1.0 in)
112 mm
(4.4 in)
8.3 Mounting details
The D1
+
is supplied with an alligator mounting clip as standard. A Klick Fast stud is available to
allow the D1
+
to be compatible with a range of wearable, wall and pole fixing kits (see product
data sheet for additional fixing kit details).
D1
+
alligator clip.
