Trolex XD1+ - 11.1 User Interface and Indicators

21
+
.
XD1+_User manual_P5650.1600_Rev A
Primary function: STEL warning
Secondary function: Sequence function icon
Primary function: TWA warning
Secondary function: Sequence function icon
Primary function: Battery indication/heartbeat
Secondary function: Sequence function icon
Icon 1
Icon 2
Icon 3
11.1 User interface icons and indicators
1
2
