Trolex XD1+ - 9. DEVICE CONFIGURATION; 9.1 Default Settings

D1
+
PERSONAL DUST MONITOR18
9. DEVICE CONFIGURATION
9.1 Default settings
Serial number ABCDEFG123 (Trolex custom S/N)
Name Blank
Operating mode Normal
Alarm PM size PM4.25
TWA period (minutes/hours) 8 hours
TWA threshold (µm/m³) 1,000
STEL period (minutes/hours) 15 minutes
STEL threshold (µm/m³) 1,000
Log rate (seconds) 10 seconds
Particle density (g/ml) 1.65
Default device settings can be manually changed as required using the Trolex BreatheLITE
application.
*It is the user’s responsibility to ensure that the D1
+
is configured in relation to local environment
operation.
XD1+_User manual_P5650.1600_Rev A
The D1
+
has been programmed with factory default settings prior to delivery which have been
detailed in the table below.
Default device settings can be manually changed as required using the Trolex BreatheLITE and
BreatheMOBILE application.
