Machine overview
4 Machine overview
4.1 General overview
No Description No Description
1 Acrylic top lid 7 Emergency stop button
2 Table 8 Keypad
3 Side panel 9 Rolls
4 Side panel for power supplies 10 Levelling feet
5 Cleaning drawer 11 Cover for cleaning opening
6 Cover for laser source 12 Cover/connection for exhaust tube
32
