Trotec Q500 User Manual

Technical Datasheet
1/
3
8057 Q500 DC/RF/DU – Technical Specifications
Mechanics
Working area
1300 mm x 900 mm (51.18 x 35.43 inches)
Loading area 1400 mm x 1150 mm (55.12 x 45.28 inches)
Working piece table
Aluminium cutting grid table or aluminium slat cutting table
Manual Z-axis on laser head
Max. Z-height
45 mm (1.77 inches)
Max. engraving speed
2 m/sec. (78.74 in/sec.)
Acceleration 15m/s² (590 in/sec²)
Max. cutting speed
0.7 m/sec. (27.56 in/sec.)
Motor
Servo motors
Optical elements
Mirrors, lens air-flushed for soil-protection
Lenses
2.0", 4.0“
Max. material load Max. 35 kg
Laser class
Class 2 – Safe operation thanks to the closed housing secured with interlocks
Features standard and accessories
Software
JobControl® Expert printer driver, JobControl® Expert laser software
Compatible with standard graphic and CAD software like Corel Draw, Adobe Illus-
trator, …
Ruby® ab Version 2.5
InPack Technology™
Protection of moving parts against dust
Air-Assist
Coaxial air assist incl. integrated pump
Laser pointer 655nm, <0,99mWcw
Laser source
Adjusted and reviewed laser source integrated
Water-cooling
The chiller is within the scope of delivery
16 l/min or 70 l/min for DU-version
Connection for exhaust
Adjustable cabinet exhaust, adjustable table exhaust
Ports: 2 x 150 mm (5.9 in) outer diameter
Additional standard features
Kill and key switch, LED-lighting, manual Z-axis on laser head, OptiMotion™, air-
cooled optics, 2.0” lens, air-assist nozzle (Ø3mm und Ø7 mm), focus-tool, alumin-
ium cutting grid table, laser class 2, CE certification, RJ45-connection for external
variable power meter

Trotec Q500 Specifications

General

Brand	Trotec
Model	Q500
Category	Cutter
Language	English
