Maintenance
8.3.5 Motion system
Information
To ensure a long service life of the machine with high quality and performance, you should spend a few
minutes per week (depending on the environment) on cleaning.
Aer cleaning the rails it is necessary to clean the table, the interior of the machine and the cleaning
drawer.
X-AXIS RAIL CLEANING
1. Clean the entire length of the x-axis rail with a cleaning
cloth and a cotton swab. Use a mild cleanser (Trotec) to
clean the bearing - contact your local Trotec Service.
Notice
Aer cleaning is the ideal time to lubricate the axles.
Y-AXIS RAIL CLEANING
1. Clean the entire length of the y-axis rails with a cleaning
cloth.
Perform this procedure on both sides.
63
