Transport
6. Remove the packing material.
7. The machine must be adjusted and installed by a
technician (see installation guide Q500).
5.7.1 Transport protection for the axes
Information
The illustrations used do not correspond to the original condition of the machine and are for information
purposes only.
-Remove the transport protectors marked in the picture,
which fix the x-axis and y-axis. To do this, remove the two
screws in each case.
5.8 Relocation of the machine
STEPS:
1. Switch off the machine.
40
