BA 8010_3.0_EN (10/2016) 35 / 68
By pressing the “Shift” key and a Z- positioning key an automatic
move to the corresponding end- positions is performed:
Shift + Down: the table moves down to the lowest possible position
Shift + Up: the table moves up to the autofocus- position.
Note: Shift + Up will cause the head moving backwards to the light
barriers (according simultaneous pressing of both z-keys).
If any of positioning keys X and Y are pressed, no moves in Z are
possible.
An automatic move of the Z- axis can be stopped by pressing any
of the positioning keys (1 or 2).
2 POSITIONING KEYS X/Y
Use the positioning keys to manually move the lens holder into the
indicated directions.
When you press two keys simultaneously, the lens holder moves
diagonally.
When you press the "Shift" key and one of the positioning keys
simultaneously, a movement to the corresponding end position is
performed.
If all panels are closed, the movement is done with the maximum
velocity, if opened, the speed is 1/4
th
of the maximum.
While the Z- axis is in movement (e.g. autofocus), no cursor moves in
X and Y axis are performed.
The status display (8) of the device is located in the center of the key
pad.
3 PAUSE
Used to stop the current working process (key lights up). As soon as
the last processing command is finished, the motion system stops.
If this key is pressed a second time, the key illumination goes off, the
interrupted working process is continued.
