True CS900 User Manual

CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS:
Step 1: Rear Stabilizer Bar:
a
) Rotate the frame forward on the Front
Stabilizer bracket (metal).
*At least one person should hold the frame,
while another person completes the remaining
Rear Stabilizer installation steps
b) For each screw, install through split washer
then flat washer
c) Insert Rear Stabilizer into the metal bracket
d) Install each screw through the bottom of the
metal bracket, then through the Rear Stabilizer
e) Tighten using the provided hex wrench
Hardware Required:
2 M8 x 70 Screws
2 M8 Washers
2 M8 Spring Washers
Step 2: Front Stabilizer Bar:
a
) Rotate the frame backwards on the Rear
Stabilizer
*At least one person should hold the frame,
while another person completes the remaining
Front Stabilizer installation steps
Truefitness.com / 800.426.6570 / 636.272.7100 10

True CS900 Specifications

General

Brand	True
Model	CS900
Category	Elliptical Trainer
Language	English
