CHAPTER 3: PRODUCT OVERVIEW
BIKE OVERVIEW (continued):
Console Assembly:
The console allows the user to set up a workout program and control the bike during a workout (For console overview and
operation instructions refer to the owner’s manual for the selected console option).
Quick Access Keys:
Allows the user to make fast, convenient adjustments the workout intensity.
Contact Heart Rate Pads:
Allows the user to check their heart rate without wearing a wireless chest strap.
Seat Adjustment Handle:
Used to adjust the vertical position of the seat to a comfortable position for the user.
Bottle Holder:
Holds an average size drink bottle for convenient use during a workout.
Pedals:
Moving part of the bike that provides resistance to the lower body during a workout.
Leveling Feet:
An adjustable system used to aid in the leveling the bike.
Battery Charge Port:
An external port used to charge the unit’s internal battery.
Coaxial Port:
Delivers television signal to the unit.
Ethernet Port:
Used to provide a network connection for compatible console options.
Power Cord:
Delivers power from the wall outlet to the bike.
Truefitness.com / 800.426.6570 / 636.272.7100 28
