CHAPTER 4A: TRANSCEND OPERATION
TRANSCEND OVERVIEW (continued):
Touchscreen Display:
A capacitive touchscreen used for workout control and feature navigation.
30 Pin iPod® Connector:
Standard 30 pin iPod connector used to connect an iPod to the console.
Headphone Jack:
Standard 3.5mm audio jack used to connect headphones to the console during media playback.
USB Jack:
Allows users to export workout data to an external USB drive or update the console software.
Auxiliary LCD Display:
Displays workout data that can be easily viewed regardless of which mode is displayed on the Touchscreen Display.
*Available on the 16” model only.
Reading Rack:
This ledge on the console can be used to hold a book, magazine, e-reader, or tablet computer during a workout.
Cooling Fan:
Integrated fan that delivers a cooling flow of air during a workout.
Warning Decal:
Important safety information for users to review prior to using the equipment.
Truefitness.com / 800.426.6570 / 636.272.7100 37
