CHAPTER 4B: ESCALATE
15
OPERATION
ADVANCED CONSOLE FUNCTIONS (continued):
Summary Screen:
The Summary Screen will be the first screen displayed after entering service mode. This screen will give a general overview
of the unit’s setup.
A) Product Model:
The model number that the console is currently configured to.
B) Serial Number:
The serial number of the console (not the base unit).
C) Tuner Type:
The type of TV tuner installed in the console.
D) Software Version:
The current version of software that is installed on the console.
E) Firmware Version:
The current version of firmware that is installed on the console.
F) BIOS Version:
The current BIOS version that is installed on the console.
G) System Software Sum:
Displays OS data that is used in the production of the console.
H) Reset Factory Defaults:
Resets all console settings to their factory defaults.
