CHAPTER 2: ASSEMBLY INSTRUCTIONS
Truefitness.com / 800.426.6570 / 636.272.7100 16
ELLIPTICAL ASSEMBLY STEPS (continued):
STEP 7: Attach Console (continued):
a) Attach the wires coming out of the top of the neck to the back of the console as shown under the picture of The
Correct Console. Remove the Ground Screw from the plate on the neck and use it to screw the Ground
Connector back into the same hole.
Note: The network cable is built in for future use and is not used for this installation.
Orange LED Console
9” TFT Console
plug here.
plug here.
To Next Page
