Truma CP plus Installation Instructions

7EN
Technical data
Display LCD, monochrome, with
background lighting
Dimensions (L x W x H) 92 x 103 x 40 mm
Operating temperature range -25°C to +60°C
Storage temperature range -25°C to +70°C
Interfaces
CP plus TIN-Bus
CP plus CI-BUS TIN-Bus, CI-BUS
Power supply 8V – 16.5V
Power consumption max. 65 mA (100 % back-
ground lighting) 6.5 mA – 10
mA (Standby)
Quiescent current
consumption 3 mA (Off)
Weight approx. 100g
Protection class Class III
Protection type IP00
Subject to technical changes.
Installation instructions
Safety instructions
In-vehicle installations must comply with
the technical and administrative regu-
lations of the respective country of use
(e.g. EN 1648, VDE 0100-721). In other
countries, the relevant regulations must
be observed. National regulations and
rules must be followed.
Scope of delivery
1 Truma CP plus control panel
1 screw (fastening control panel upper section)
4 screws for wall mounting (depending on type)
1 operating instructions
1 installation instructions1
1 connector cable CP plus
1 Mounting frame DBT
To be ordered separately:
Connector cable (TIN bus) available in different lengths.
Description
The Truma CP plus control panel (with polarity reversal protec-
tion) is supplied with voltage via a 12 V connector cable. The
control panel is connected to a Combi CP plus ready heater
and / or an air conditioning system or a Truma iNet Box via a
connector cable (TIN bus). The independently installed CP plus
control panel is suitable for wall mounting on a level surface.

Truma CP plus Specifications

General

Display	LCD
Power supply	12 V DC
Quiescent current consumption (at 12 V)	Approx. 5 mA
Temperature range	-15 °C to +60 °C
Protection class	IP20
Compatibility	Truma Combi heaters
