Truma CP plus User Manual

18
34020-01385 · 00 · 07/2022
EN
Operation Truma CP plus
Fan modes in heater mode (HEATER)
Symbol Displayed
text
Description
ECO Low fan level
HIGH High fan level
BOOST Rapid room heating is availa-
ble if the difference between
the selected and current
room temperatures is more
than 10°C�
When the heater is switched on (room temperature, hot
water level set), the status line (2) shows the fan mode
that was selected the last time the heater was running�
The factory setting is “ECO”�
Fan modes in air conditioning mode(AC)
Symbol Displayed
text
Description
OFF Fan is switched off� (can be
selected only if no appli-
ance is in operation)�
Symbol Displayed
text
Description
LOW Low fan level
MID Medium fan level
HIGH Highest fan level
NIGHT Ultra-quiet fan operation
Fan modes in automatic climate control
mode(AUTO)
Symbol Displayed
text
Description
AUTO Automatic fan level selec-
tion� Cannot be changed in
AUTO mode�
Only “ECO” is available for heaters�
If the 230 V power supply (mains electricity) is interrupt-
ed, all functions associated with air conditioning system
or automatic climate control modes are deactivated and
blanked out on the CP plus�

Truma CP plus Specifications

General

Display	LCD
Power supply	12 V DC
Quiescent current consumption (at 12 V)	Approx. 5 mA
Temperature range	-15 °C to +60 °C
Protection class	IP20
Compatibility	Truma Combi heaters
