2.1 Technical data
quicksharp
Workpiece:
Clamping diameter 150 mm
Min. height 25 mm
Max. height 130 mm
Wheel motor:
Speeds 2800 - 3360 min
-1
Voltages 200 - 265 V/350 - 460 V
Cycles 50/60 Hz
Power 1.1 kW
Grinding wheel diameter 125 mm
Grinding wheel height 23 mm
Cutting speed 20 m/s
Workpiece speed 40 min
-1
Feedrate 0.1 mm/min
Regrind amount per grinding
operation 0 - 0.5 mm
Dimensions 600 x 600 x 1780 mm
Weight 300 kg
Hydraulic oil - container volume 5 l
Grinding coolant - container volume 20 l
Noise emission The typical A-effective sound level of the
unit is lower than 70 dB(A).
2.2 EC Declaration of Conformity
as defined by EC Machinery Directive 89/392/EEC, Annex IIA
We herewith declare that the machine indicated below, owing to its
engineering concept and construction and the model as introduced on
the market, complies with the relevant essential safety and health
provisions stipulated in the EC directive.
This declaration shall lose its validity if any changes are made to the
machine without our authorization.
Machine designation: Tool Grinding Machine
Machine type: quicksharp
Applicable EC directives: EC Machine Directive 89/392/EEC;
91/368/EEC, 93/44/EEC
EC Low Voltage Directive
(73/23/EEC)
EC-EMC Directive (89/336/EEC)
Applied harmonized stan-
dards, in particular: EN 292-1, EN 292-2, EN 60 204-1,
EN 55022, EN 55014
Hans Klingel
Director of Development
TRUMPF GmbH + Co.
D-71254 Ditzingen
8 quicksharp B60E
