3. Move, Store and Install the Machine
3.1 Pre-installation Preparation Works
1. Power source: required power supply specification:
Power
Voltage
Frequency
Phase
Specification
220V
60 HZ
3+Neutral+Earth
2. Pneumatic - air pressure used to clean up spindle, cool down cutting is 5 ~ 7 KG/CM
2
,
at least 90 NL/min of supply.
3. Oils: feed in required oils before starting this Machine:
Purpose
Product name
Viscosity (40°C)
Capacity
Remark
Lube oil
Guide-way oil
61.2 ~ 74.8
2L
ISO VG68,R-68, K68
4. Precision measuring equipment:
1. 0.02mm/M level meter, at least two pieces.
2. Gauge-carried magnetic seat 1/100, 2/1000mm, one or more set each.
3. One granite right-angle ruler.
5. Space requirement:
To plan for Machine layout space, reserve sufficient space for the
operation/maintenance and access to and from the machine.
