3.5 Compressed Air Source
1. Use clean air source.
2. Confirm that the air source can provide necessary air flow-rate.
3. Air pressure should exceed 6 kg/cm
2
.
4. Arrangement of reserved pipelines:
(1) Compressed air must be filtered and be clean and dry (dew point, 6 kgf/cm
2
,
10°C).
(2) Supply or compressed air must satisfy Machine’s consumption requirement (1-hp
air compressor that supplies 9 0NL/min is approx. enough).
(3) Refer to the drawing below for the input points of compressed air and power
supply.
The compressed air fast-connector size is 9.525 mm (3/8 in.).
.
3.6 Other Objects
Clean Utensils Requirement Table
