Tryax TY30-VS - Machine Brief Introduction; Mechanical Specification

6
2. Machine Brief Introduction
2.1 Mechanical Specification
Standard accessories：
1. Digitising Probe
2. Diamond Cutter
3. USB & Etherent Ports
4. Halogen Work Light
5. Auto Lube
6. Way Covers
7. Chip Tray
8. Tools & Tool Box
9. Four Way Tool Post
TY30-VS SPECIFICATION
Model
Unit
VTL30
Control
Control System
BECKHOFF
Travel
X-axis Travel
mm(inch)
508(20")
Z-axis Travel
mm(inch)
457(18")
Max.Turning Diameter
mm(inch)
762(30")
Table
Jaw Chuck(Manual)with Soft Jaw
inch
16" - 3
Distance
Distance from Spindle end to Table
mm(inch)
0-457(0~18")
Spindle Nose Taper / Tool
A2-6
Spindle
Spindle Speed
rpm
60~1000
Spindle Type
Belt Drive
Spindle Motor
KW(HP)
7.6(10HP)/4P
2 axes Servo Motors (X/Z)
KW
1.3
Feed
X-axis Rapid Traverse
M/min
10 / Direct
Drive
Z-axis Rapid Traverse
M/min
10 / Direct
Drive
Cutting Feedrate
M/min
10
Min. Input Unit
mm/min
0.001
Installation
Requirements
Weight (about)
t
2
