4.2 Oil-feed and Oil Types
1. The Machine two axis guide-ways and ball screw are under forced-lubrication
operation with auto oil-feeding.
2. Prior to booting, check if lube oil is sufficient.
3. Always use the correct lube oil; incorrect oil will reduce Machine’s lifetime and may
cause malfunction.
4. Lube oil flow-rate is adjusted prior to delivery. Unless the loop is clogged or faulty, do
not adjust it.
4.2.1 Machine’s Oil-feed Points
The following diagram presents the Machine’s oil-feed points. While feeding or replacing
oil, do it at the specified oil-feed points (see the recommended oil list shown in next page).
4.2.2 Referenced Machine Oils
Recommended oil list:
