Tryax TY30-VS - Soft jaw chuck Mechanism; Forced Auto Lubricator

26
5.2 Soft jaw chuck Mechanism
5.3 Forced Auto Lubricator
Electric Lubricator specification
Type
Lubricating
time
Intermediate
time
Maximum
flow-rate
Maximum
pressure
JY19B
1-99 sec.
1-99 min.
180 c.c/min
8 kg/cm
2
Floating-ball
switch
Oil tank capacity
Three-phase
voltage
Motor output
power
Connector
diameter

2 L
220V/0.3A
51 W
PT 1/8
Graphical demonstration:
Manually start
switch
Oil-feed
opening
