Tryax TY30-VS - Machine Parts List (Base Unit)

32
No.
Drawing No.
Name
Specification
Material
Quantity
1
WL30VSB001A
Base
FC25
1
2
WL30VST002A
Soft Jaw
6061
3
3
WL30VST001
Chuck
SK-16
Purchase products
1
4
WL30VSB029
Chuck adapter plate
S45C
1
5
WL30VSB021
Spindle the front cover
SS41
1
6
WL30VSB022
Principal axis
S45C
1
7
M14
Hex socket cap screws
M14x50
Purchase products
9
8
M10
Hex socket cap screws
M10x40
Purchase products
2
9
BH30216080
Tapered roller bearings
30216
Purchase products
1
10
BH30215075
Tapered roller bearings
30215
Purchase products
1
11
YF04015058
Precision lodnuts
YSF
Purchase products
1
12
WL30VSB011
Motor adjustment plate
SS41
1
13
SV0850H022
Adjustment Pads
SS41
1
14
WL30VSB019
Headstock
FC25
1
15
WL30VSB024
Spindle cover plate
SS41
1
16
B601407002
Bearing
6014
Purchase products
1
17
WL30VSB020
Bearing gland
SS41
1
18
WL30VSB018
Pulley
S45C
1
19
WL30VSB012
Pulley
S45C
1
20
SD07011060
Power lock
DL-SD-70
Purchase products
1
