TSC MH241 Series User Manual

36
 After clicking Set button, it'll pop-up the window tip
as below shown.
 IP address will be shown in the “IP address” field
and the Wi-Fi logo and IP address will be displayed
on the LCD control panel.
Note:
IP address should be shown within about 5~15
seconds after printer turn on. If not, please refer to
steps below to initialize the printer Wi-Fi module
settings then to setup it again.
 Remove the cable between the computer and the
printer.
 Go to main page, click Add Printer to add the
printer via Network.
 Select the printer and enter the setting page by
double clicking the printer.
 Click the Print Test Page button to print the test
page via Wi-Fi interface.

TSC MH241 Series Specifications

General

Resolution	203 dpi
Max. Print Width	104 mm
Interface	Ethernet
Scanning Method	Thermal Transfer/Direct Thermal
Supported Barcode Types	1D Barcodes
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	60°C
Humidity	25-85% non-condensing
Weight	MH241/MH241T/MH241P: 15 kg MH341/MH341T/MH341P: 15 kg MH641/MH641T/MH641P: 15 kg
