TSC TC200 Series

TC200/ TC300/ TC210/ TC310
Bar Code Printer Service Manual
31
4. Put back the lower inner cover. Place the cutter module into both side notches of
lower inner cover as picture below, then push cutter to lock into the lower inner
cover.
5. Close the top cover and then upside down the printer.
6. Fasten the 6 screws at the lower inner cover.
7. Place the printer in the flat and secured desktop for media loading and printing.
