TSC TC200 Series

TC200/ TC300/ TC210/ TC310
Bar Code Printer Service Manual
35
The printing position of
small label is incorrect
* Media sensor sensitivity
is not set properly.
* Label size is incorrect.
* The parameter Shift Y is
incorrect.
* The vertical offset
setting in the driver is
incorrect.
* Calibrate the sensor sensitivity again.
* Set the correct label size and gap
size.
* Use DiagTool to fine tune the
parameter of Shift Y.
* If using the software BarTender,
please set the vertical offset in the
driver.
