10
3.2 Replacing the Linerless Platen Roller (Option)
1. Open the media cover by pressing the media cover release button.
2. Pull up and remove the linerless platen roller through the slots as indicated.
3. Remove/Replace the linerless platen roller.
4. Reassemble the parts in the reverse procedures.
Slots
Linerless Platen Roller
