TSC TDP-225 Service Manual

TDP-225 Series
Bar Code Printer Service Manual
28
4.3 LCD display (Option for TDP-225/324 model)
This section lists the LCD display messages that you may encounter when operating
the printer. Also, it provides solutions.
Messages
Possible Cause
Recovery Procedure
Head Open
* The printer top cover is open.
* Please close the top cover.
No Paper
* Running out of label.
* The label is installed incorrectly.
* Gap/black mark sensor is not
calibrated.
* Supply a new label roll.
* Please refer to the steps in user’s
manual to reinstall the label roll.
* Calibrate the gap/black mark
sensor.
Paper Jam
* Gap/black mark sensor is not
set properly.
* Make sure label size is set
properly.
* Labels may be stuck inside the
printer mechanism.
* Calibrate the gap/black mark
sensor.
* Set label size correctly.
Out of Mem
* The space of FLASH/DRAM or
MicroSD card is full.
* Delete unused files in the
FLASH/DRAM or MicroSD card.
Take Label
* Peel function is enabled.
Waiting user to take label away
to print the next label.
* Please take the label away to print
the next label if peeler module is
installed.
* If peeler module is installed and
label is been taken away, but the
message remains. Please check if
the peeler module connector is
connected to main board properly.
* If peeler module is not installed,
please disable the peeler function.
Cutter Error
* Cutter jam.
* There is no cutter installed on
the printer.
* Cutter or cutter driver circuit
board is damaged.
* Remove the jammed label.
* Make sure the media thickness is
equal or less than 0.19mm.
* Replace the cutter or cutter driver
circuit board.

TSC TDP-225 Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
Maximum resolution	203 x 203 DPI
Maximum print height	2286 mm
Maximum printing width	54 mm
Ethernet LAN	No
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Certification	FCC, CE, TUV, CUL, UL, CCC, C-Tick
Internal memory	8 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in processor	RISC 32-bit
Compatible memory cards	SD
Power requirements	100 - 240
AC adapter output current	2 A
AC adapter output voltage	24 V
Display	LCD
Product color	-
Core diameter	38 mm
Ribbon length	90 m
Media thickness	0.06 - 0.19 mm
Maximum label width	60 mm
Maximum label length	2.286 m
Maximum roll diameter	127 mm
Supported paper width	15 - 60 mm
Maximum media length (imperial)	90 \
Supported paper width (imperial)	0.59 - 2.36 \
LED indicators	Power, Status
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	41 - 104 °F

Weight and Dimensions

Depth	209 mm
Width	109 mm
Height	171 mm
