TSC TDP-225

TDP-225 Series
Bar Code Printer Service Manual
12
3.2 Replacing the Main Board and RS-232 (Ethernet interface
board/ Option for TDP-225/324 model)
1. Open the top cover and remove the lower front cover.
2. Close the top cover. Then turn the printer upside down and use the screwdriver to
remove the 4 screws from lower cover.
3. Remove the lower cover.
Lower front cover
Screws
Screws
