TSC TTP-2410MT Series Service Manual

21
21
3.6 Replacing the Platen Roller Assembly
1. Open printer right side cover.
2. Disengage print head lift lever.
3. Remove 2 screws to remove lower front panel.
4. Remove 2 screws on the platen holder.
5. Take out the platen holder, platen roller assembly and replace a new platen roller
assembly.
6. Reassemble the parts in the reverse procedures.
Screws
Platen roller assembly
Holder
Screws
