TSC TTP-2410MT Series User Manual

- 6 -
1.6 Media Specifications
Media Specifications
203 dpi models
300 dpi models
600 dpi models
Label roll capacity
208.3 mm (8.2”) OD
Media alignment
Edge alignment
Media type
Continuous, die-cut, Fan-fold, tag, notched, black mark,
perforated, care label (width less than 3 inch)
Media wound type
Printing face outside wound
Media width
25.4~116mm (1" ~ 4.5")
Media thickness
0.06~0.30 mm (2.3~11.8 mil), max. 300g/m
2
Media core diameter
25.4~76.2 mm (1”~3”)
Label length
5~25400 mm
(0.20”~1000”)
5~11,430mm
(0.20”~450”)
5~2540mm
(0.20”~100”)
Label length
(cutter mode)
25.4~4064 mm
(1”~ 160”)
25.4~1854 mm
(1”~73”)
25.4~1016 mm
(1”~40”)
Label length
(peeler mode)
25.4~152.4 mm (1”~6”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
