6. Unlock the media sensor lock lever to adjust the media sensor, make sure the gap or black mark
sensor is at the location where media gap/black mark will pass through for sensing.
Note:
* The sensor location is marked by a triangle mark ▽ at the sensor housing.
* The media sensor position is moveable, please make sure the gap or black mark is at the
location where media gap/black mark will pass through for sensing.
7. Adjust front label guide to fit the
width of the label.
8. Close the print head mechanism.
Make sure the latches are
engaged securely.
9. Using the front display panel, set
media sensor type and calibrate
the selected sensor.
Note:
* Please calibrate the gap/black
mark sensor when changing
media.
* Please refer to video on TSC
YouTube or driver CD.
