TSC TTP-2410MT Series User Manual

- 29 -
7. Wrap the label onto the internal rewind spindle and wind the spindle counter-clockwise about 3~5
circles until the label is properly stretched.
8. Lift up the peel-off roller release lever and close the print head mechanism.
9. Peeling will automatically start. Press the
FEED button to test.
PUSH
PUSH
