TSC TTP-286MT Series - General Specifications; Print Specifications; Ribbon Specifications

- 5 -
1.3 General Specifications
General Specifications
Physical
dimensions
440 mm (W) x 336 mm (H) x 514 mm (D)
17.32” (W) x 13.23” (H) x 19.84” (D)
Weight
23.7 kg
Power
Internal switching power supply
Input: AC 100-240V, 3.0A, 50-60Hz
Output: DC 24V, 8.33A, 200W
Environmental
condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 20~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
Environmental
concern
Comply with RoHS, WEEE
1.4 Print Specifications
Print Specifications
203 dpi
models
300 dpi
models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Thermal transfer/ or direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 12 dots)
Print speed
(inches per second)
Up to 6 ips
Up to 4 ips
Max. print width
216 mm
219.5 mm
Max. print length
11,430 mm (450”)
5,080 mm (200”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
Max. OD 90 mm
Ribbon length
600 meter
Ribbon core inside diameter
1” core (25.4 mm)
Ribbon width
110 mm ~ 254 mm (4.33”~10”)
Ribbon wound type
Ink coated outside
Note: Support color ribbon
