TSC TTP-286MT Series - Media Specifications

- 6 -
1.6 Media Specifications
Media Specifications
203 dpi models
300 dpi models
Label roll capacity
208.3 mm (8.2”) OD
Media alignment
Center bias
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Printing face outside wound
Media width
101.6~241.3 mm (4" ~ 9.5")
Media width (cutter mode)
101.6~215.9 mm (4”~8.5”)
Cutter max. media width 225mm
Media thickness
0.06 ~ 0.254 mm (2.36 ~ 10 mil)
Media core diameter
76.2 mm (3”)
Media length
25.4~1270 mm (1.0”~50”)
Media length
(cutter mode)
25.4~1270 mm (1.0”~50”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
