5.8 Diagnostics
5.8.1 Print Config.
This feature is used to print current printer configuration to the label. On the configuration
printout, there is a print head test pattern, which is useful for checking if there is any dot
damage on the print head heater element.
Self-test printout
Model name
F/W version
Firmware checksum
Printer S/N
TSC configuration file
System date
System time
Printed mileage (meter)
Cutting counter
Print speed (inch/sec)
Print darkness
Label size (inch)
Gap distance (inch)
Gap/black mark sensor
intension
Code page
Country code
Menu Diagnostics
Print Config.
Dump Mode
Print Head
Display
Sensor
Menu Diagnostics Print Config.
