TSC TTP-286MT

- 19 -
3.3 Loading the Media
3.3.1 Loading Roll Labels
1. Lift the handle to open the printer right
side cover. Push the print head release
lever to open the print head
mechanism.
2. Remove one label roll guard from the
label spindle.
3. Make sure the width of the label. (You
can refer to the ruler on the spindles.)
The space is reserved for
the pairs of label roll
guards.
