TSI Instruments Aerotrak 9303 Service Manual

5-2 AeroTrak
®
Handheld and Remote Airborne Particle Counters
Part Number
Description
S7000007
9303 Case Kit (TSI
®
)
(1) Case, Top
(1) TSI
®
Logo
(1) Key Pad
(1) Model Label
(1) Battery Foam
(1) Screw (battery cover)
S7000008
9303 Case Kit (BioTest)(MK)
(1) Case, Top
(1) BioTest Logo
(1) Key Pad
(1) BioTest Model Label
(1) Battery Foam
(1) Screw (battery cover)
S7000009
9303 Laser Diode and For 7301, 7501, 7510, 7301-P
Remote Models
(5) Laser Diode
S7000010
9303 Cable Kit
(5) 6002091 CBL Assembly 4.5" 2 Pin X-Over Twisted
(5) 6002092 CBL Assembly 1.5" 3 Pin X-Over
(5) 6002093 CBL Assembly 3" 4 Pin X-Over
(5) 6002485 CBL Assembly 2.75" 5 Pin X-Over
S7000011
9303 O-Ring Kit
(50) 2 x 20 mm (mirror)
(50) 1.5 x 12 mm (beam block)
(50) 1 x 8 mm (sample inlet & outlet)
(50) 1.5 x 10 mm (New Design sample inlet & outlet)
(block)
(50) 1 x 7 mm (nozzle inlet)
S7000012
9303 Hardware Kit
(100) M3 x 6 mm PAN HD PHH
(100) M3 x 0.5 x 8 mm SKT HD CAP
(10) Nylon Standoff (display mounting)
(100) Battery Cover Screw
S7000031
AeroTrak
®
9303 Laser Alignment Fixture
(1) Required to align laser diode after replacement in 9303
and remotes
S7000035
9303 Inlet Nozzle
(1) Nozzle, Inlet, 0.1 CFM CC 3 CH OPC
700195
Battery Lithium
(1) Battery Lithium 3V Coin
S7000036
Inlet Remotes 7201F, 7510, 7510F Kit
(1) Nozzle, Inlet, 1.0 CFM CC OPC
S7000037
Outlet Remote 7201F Kit
(1) Nozzle, Outlet w Taps 7201 w 2.7 LPM Cool Flw
S7000038
Inlet Remote 7310 Kit
(1) Nozzle, Inlet CC 7310 1.8 X 3.6mm Ovl; 1 CFM

TSI Instruments Aerotrak 9303 Specifications

General

Size Range .	0.3 to 25 µm
Channel Sizes .	0.3 µm and 5.0 µm fixed; 0.5, 1.0, 2.0, or 2.5 µm selectable middle channel.
Counting Efficiency .	50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501-4 and JIS)
Concentration Limits .	2, 000, 000 particles/ft3 at 5% coincidence loss
Zero Count Level .	<1 count / 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate .	0.1 CFM (2.83 L/min)
Calibration .	NIST traceable with TSI® calibration system
Sampling Modes .	Manual and automatic
Sampling Time .	1 second to 99 minutes 59 seconds
Sampling Frequency .	1 to 999 cycles or continuous
Light Source .	Long life laser diode
Sample Probe/Tubing .	Isokinetic sampling probe
Exhaust .	Internal HEPA filter
Vacuum Source .	Internal pump
External Surface .	High impact injection molded plastic
Communication Mode .	USB serial output
Data Storage .	1, 500 sample records
Status Indicators .	Low battery and service
Display .	3.2-in. (8.1 cm) 160 x 160 monochrome LCD
AC Power . (power to AC adapter)	110 to 240 VAC 50-60 Hz Universal in-line power supply with country specific plugs
DC Power . (power to instrument)	9 VDC @ 1.5 A
Battery .	Rechargeable Li-Ion
Battery Life .	Up to 4.5 hours of continuous use
Recharge Time .	< 3 hours

Weight and Dimensions

Dimensions (L x W x H)	9.1 x 6.3 x 2.4 in. (23 x 11 x 6.2 cm) (without isokinetic inlet)
Weight .	1.3 lbs (0.58 kg) with battery
