TSI Instruments Aerotrak 9303 Service Manual

Service Kits for Replacement Components 5-3
Part Number
Description
S7000039
Inlet Remotes 7301, 7501, 7301F, 7501F Kit
(1) Nozzle, Inlet, 0.1 CFM CC OPC
S7000040
Outlet Remote 7301F, 7501F Kit
(1) Nozzle, Outlet, Pressure Taps CC OPC
S7000041
Outlet Remotes 7301, 7501 Kit
(1) Nozzle, Outlet CC OPC
S7000043
Outlet Remotes 7510 Kit
(1) Nozzle, Outlet CC OPC
S7000044
Outlet Remote 7310F, 7510F Kit
(1) Nozzle, Outlet CC OPC
S7000137
9303 Inlet Nozzle (New Design)
(1) Nozzle, Inlet, 0.1 CFM CC 3 CH OPC
S7000138
Inlet Remotes 7201F, 7510, 7510F Kit (New Design)
(1) Nozzle, Inlet, 1.0 CFM CC OPC
S7000139
Outlet Remote 7201F Kit (New Design)
(1) Nozzle, Outlet w Taps 7201 w 2.7 LPM Cool Flw
S7000140
Inlet Remote 7310 Kit (New Design)
(1) Nozzle, Inlet CC 7310 1.8 X 3.6 mm Ovl; 1 CFM
S7000141
Inlet Remotes 7301, 7501, 7301F, 7501F Kit (New Design)
(1) Nozzle, Inlet, 0.1 CFM CC OPC
S7000142
Outlet Remotes 7301, 7501 kit (New Design)
(1) Nozzle, Outlet CC OPC
S7000143
Outlet Remotes 7510 Kit (New Design)
(1) Nozzle, Outlet CC OPC
S7000144
Outlet Remote 7310F, 7510F Kit (New Design)
(1) Nozzle, Outlet CC OPC
S7000150
Tool Kit
(1) Small Beam Dump/Mirror Tool
(1) Large Beam Dump Tool
(1) T-handle Large Mirror Tool
(1) Stand
6001577
7301-P Filters, HEPA
(1) HEPA, 3.2" Long x .19 Tube Stubs
S7000156
7301-P Inlet
(1) Nozzle, Inlet, 7001635
S7000157
7301-P Outlet
(1) Nozzle, Outlet, 7001636
S7000159
7301-P Hardware Kit
(100) 5050131 SCR M3 x 6 PAN HD PHH SS
(100) 6002318 SCR M3 x .5 x 10 mm PAN HD PHH SS
(100) 5000188 SCR M3 x .5 x 6 mm SS NYL TIP SET
(100) 6002210 SCR M3 x .5 x 3 mm SSS NYLON TIP SS
(100) 6002013 SCR M1.6 x 0.35 x 6 mm SKT HD CAP BLK
(100) 5038160 SCR 4-40 x 1/4 BTN HD SKT SS
(100) 5050133 SCR M3 x 4 PAN HD PHH ZI STL
(100) 6003526 SCR 4-40 x 3/16 PPH EXT TOOTH SEMS
(100) 5070150 SCR 6-32 x 3/8 TRUSS HD PHH SS

TSI Instruments Aerotrak 9303 Specifications

General

Size Range .	0.3 to 25 µm
Channel Sizes .	0.3 µm and 5.0 µm fixed; 0.5, 1.0, 2.0, or 2.5 µm selectable middle channel.
Counting Efficiency .	50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501-4 and JIS)
Concentration Limits .	2, 000, 000 particles/ft3 at 5% coincidence loss
Zero Count Level .	<1 count / 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate .	0.1 CFM (2.83 L/min)
Calibration .	NIST traceable with TSI® calibration system
Sampling Modes .	Manual and automatic
Sampling Time .	1 second to 99 minutes 59 seconds
Sampling Frequency .	1 to 999 cycles or continuous
Light Source .	Long life laser diode
Sample Probe/Tubing .	Isokinetic sampling probe
Exhaust .	Internal HEPA filter
Vacuum Source .	Internal pump
External Surface .	High impact injection molded plastic
Communication Mode .	USB serial output
Data Storage .	1, 500 sample records
Status Indicators .	Low battery and service
Display .	3.2-in. (8.1 cm) 160 x 160 monochrome LCD
AC Power . (power to AC adapter)	110 to 240 VAC 50-60 Hz Universal in-line power supply with country specific plugs
DC Power . (power to instrument)	9 VDC @ 1.5 A
Battery .	Rechargeable Li-Ion
Battery Life .	Up to 4.5 hours of continuous use
Recharge Time .	< 3 hours

Weight and Dimensions

Dimensions (L x W x H)	9.1 x 6.3 x 2.4 in. (23 x 11 x 6.2 cm) (without isokinetic inlet)
Weight .	1.3 lbs (0.58 kg) with battery
