TSI Instruments Aerotrak 9303 Service Manual

5-4 AeroTrak
®
Handheld and Remote Airborne Particle Counters
Part Number
Description
S7000160
7301-P Cable Kit
(5) 6003735 Cable tie, 10-3/4 Long, 60 lb
(5) 1303824 CBL ASSY 2.1 mm PWR RTANG
(5) 6003430 CBL CAT5e 1-ft Patch Cable Yellow
(5) 6003427 CBL RJ11 (6 x 4) to RJ11 (6x4) 1 ft
(5) 6002144 CBL ASSY 1.5" 4 PIN X-OVER TWISTED
(5) 6002485 CBL ASSY 2.75" 5 PIN X-OVER
(5) 6002143 CBL ASSY 2" 2 PIN X-OVER TWISTED
(5) 6002092 CBL ASSY 1.5" 3 PIN X-OVER
S7000161
Detector PCB for 7310 Remotes
(1) Detector PCB 6002413
(1) Shield 6001618
S7000162
Outlet Remotes 7301F, 7501F Kit New Design
(1) Nozzle, Outlet CC OPC
S7000165
Analog Output PCB Assembly for 7XXX-AXF
(1) 6005083 Main Analog Interface PCA
(1) 1606023 Feet Black Bumpon 0.75 DIA
S7000169
7301-P 12V Pump & PCA Kit
(1) Pump, 12V Diaphragm, Brushless
(2) Filter HEPA, 3.2" Long x .19 Tube Stubs
(2) Screws, M4 x 4 mm Long, ZN-PS
(2) Screws, 4-40 x 3/16 PPH EXT TOOTH SEMS
(1) 12” TU TYGON 0.250 OD x 0.125 ID
(2) CABLE TIE 5 1/2" LONG x .14 WIDE BLUE
(1) PCA SPI FLOW CONTROL 6005424
S7000170
7301-P Pump Kit 12V
(1) Pump, 12V Diaphragm, Brushless
(2) Filter HEPA, 3.2" Long x .19 Tube Stubs
(2) Screws, M4 x 4 mm Long, ZN-PS
(2) Screws, 4-40 x 3/16 PPH EXT TOOTH SEMS
(1) 12” TU TYGON 0.250 OD x 0.125 ID
(2) CABLE TIE 5 1/2" LONG x .14 WIDE BLUE
S7000176
7301-P Flow Control board 12V
(1) PCA SPI FLOW CONTROL 6005424
S7000185
7310 Replacement Laser/Optics Block Assembly (qty 1)
S7000226
7201 Replacement Laser/Optics Block Assembly (qty 1)
S7000238
Remote Nozzle Cleaning Swabs (Kit)
(20) – Wire Cotton swab
(20) – Gray swab
(20) – Green swab
S7000239
Laser Alignment Target Assembly
S7000267
Detector PCB for 7201 Remotes
(1) Detector PCB 6008098
(1) Shield 6001618

TSI Instruments Aerotrak 9303 Specifications

General

Size Range .	0.3 to 25 µm
Channel Sizes .	0.3 µm and 5.0 µm fixed; 0.5, 1.0, 2.0, or 2.5 µm selectable middle channel.
Counting Efficiency .	50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501-4 and JIS)
Concentration Limits .	2, 000, 000 particles/ft3 at 5% coincidence loss
Zero Count Level .	<1 count / 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate .	0.1 CFM (2.83 L/min)
Calibration .	NIST traceable with TSI® calibration system
Sampling Modes .	Manual and automatic
Sampling Time .	1 second to 99 minutes 59 seconds
Sampling Frequency .	1 to 999 cycles or continuous
Light Source .	Long life laser diode
Sample Probe/Tubing .	Isokinetic sampling probe
Exhaust .	Internal HEPA filter
Vacuum Source .	Internal pump
External Surface .	High impact injection molded plastic
Communication Mode .	USB serial output
Data Storage .	1, 500 sample records
Status Indicators .	Low battery and service
Display .	3.2-in. (8.1 cm) 160 x 160 monochrome LCD
AC Power . (power to AC adapter)	110 to 240 VAC 50-60 Hz Universal in-line power supply with country specific plugs
DC Power . (power to instrument)	9 VDC @ 1.5 A
Battery .	Rechargeable Li-Ion
Battery Life .	Up to 4.5 hours of continuous use
Recharge Time .	< 3 hours

Weight and Dimensions

Dimensions (L x W x H)	9.1 x 6.3 x 2.4 in. (23 x 11 x 6.2 cm) (without isokinetic inlet)
Weight .	1.3 lbs (0.58 kg) with battery
