TSI Instruments PRESSURA RPC30 User Manual

BACnet
®
MS/TP Object Set 103
Object Type
Device
Instance
*Units
Description
Writable
Notes and Range
Object
Value
Analog Value
3
in. W.C., Pa
Room 1 Pos Low
Alarm
Y
0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
4
in. W.C., Pa
Room 1 Pos High
Alarm
Y
0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
5
cfm, l/s, CMH
Room 1 Low
Exhaust Alarm
Y
0 to 30,000 cfm
Analog Value
6
cfm, l/s, CMH
Room 1 Low Supply
Alarm
Y
0 to 30,000 cfm
Analog Value
7
°F, °C
Room 1 Low
Temperature Alarm
Y
50 to 85°F
Analog Value
8
°F, °C
Room 1 High
Temperature Alarm
Y
50 to 85°F
Analog Value
9
% RH
Room 1 Low RH
Alarm
Y
0 to 100
Analog Value
10
% RH
Room 1 High RH
Alarm
Y
0 to 100
Analog Value
11
ft
3
, m
3
Room 1 Volume
Y
0 to 20,000
Analog Value
12
Room 1 Neg
Setpoint
Y
0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer.
Analog Value
13
Room 1 Pos
Setpoint
Y
0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer.
Analog Value
14
cfm, l/s, CMH
Room 1 No
Isolation Setpoint
Y
Flow: 0 to 30,000
% Open: 0 to 100
Analog Value
15
°F, °C
Occupied Mode
Heating Setpoint
Y
55 to 85 °F
Analog Value
16
°F, °C
Occupied Mode
Cooling Setpoint
Y
55 to 85 °F
Analog Value
17
°F, °C
Unoccupied Mode
Heating Setpoint
Y
55 to 85 °F
Analog Value
18
°F, °C
Unoccupied Mode
Cooling Setpoint
Y
55 to 85 °F
Analog Value
19
°F, °C
Heating Mode
Supply
Temperature Delta
Y
10 to 40°F
Analog Value
20
cfm, l/s, CMH
Occupied Mode
Minimum Supply
Flow
Y
0 to 10,000 cfm
Analog Value
21
cfm, l/s, CMH
Maximum Supply
Flow
Y
0 to 10,000 cfm
Analog Value
22
cfm, l/s, CMH
Occupied Mode
Heating Flow
Y
0 to 10,000 cfm
