TSI Instruments PRESSURA RPC30 User Manual

Appendix B
104
Object Type
Device
Instance
*Units
Description
Writable
Notes and Range
Object
Value
Analog Value
23
cfm, l/s, CMH
Occupied Mode
Cooling Flow
Y
0 to 10,000 cfm
Analog Value
24
cfm, l/s, CMH
Unoccupied Mode
Minimum Supply
Flow
Y
0 to 10,000 cfm
Analog Value
25
% Open
Minimum Supply
Control Output
Y
0 to 100
Analog Value
26
% Open
Maximum Supply
Control Output
Y
0 to 100
Analog Value
27
cfm, l/s, CMH
Min Exhaust Flow
Y
0 to 10,000 cfm
Analog Value
28
cfm, l/s, CMH
Max Exhaust Flow
Y
0 to 10,000 cfm
Analog Value
29
% Open
Minimum Exhaust
Control Out
Y
0 to 100
Analog Value
30
% Open
Maximum Exhaust
Control Output
Y
0 to 100
Analog Value
31
in. W.C., Pa
Anteroom Neg Low
Alarm
Y
2 room configuration only
-0.19500 to
+0.19500 in. W.C.:TSI
Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
32
in. W.C., Pa
Anteroom Neg High
Alarm
Y
2 room configuration only
-0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
33
in. W.C., Pa
Anteroom Pos Low
Alarm
Y
2 room configuration only
-0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
34
in. W.C., Pa
Anteroom Pos High
Alarm
Y
2 room configuration only
-0.19500 to
+0.19500 in. W.C.:
TSI Sensor
-1.0 in. W.C. to 1.0 in. W.C.:
Pressure Transducer
Analog Value
39
Alarm Delay
Y
1 to 600 seconds
Analog Value
40
Mute Timeout
Y
1 to 60 minutes
Analog Value
41
Door Delay
Y
1 to 600 seconds
Analog Value
42
Address
Y
1 to 127
Analog Value
43
MAC ID (Device ID)
Y
0 to 4,194,302
Analog Value
44
Current Heating
Control Setpoint
N
55 to 85 °F
Analog Value
45
Current Cooling
Control Setpoint
N
55 to 85 °F
Binary Input
1
Room 1 Door
Switch
0 Door Closed (Normal)
1 Door Open
Binary Input
2
Anteroom Door
Switch
0 Door Closed (Normal)
1 Door Open
