TSI Instruments PRESSURA RPC30 User Manual

BACnet
®
MS/TP Object Set 105
Object Type
Device
Instance
*Units
Description
Writable
Notes and Range
Object
Value
Binary Input
4
Room 1 Occupancy
0 Occupied (Normal)
1 Unoccupied
Binary Input
5
Anteroom
Occupancy
0 Occupied (Normal)
1 Unoccupied
Binary Value
1
Room 1 High Alarm
Y
0 Disable
1 Enable
Binary Value
2
Room 1 Low Alarm
Y
0 Disable
1 Enable
Binary Value
3
Anteroom High
Alarm
Y
0 Disable
1 Enable
Binary Value
4
Anteroom Low
Alarm
Y
0 Disable
1 Enable
Multi-State
Value
1
Number of Rooms
1 Single
2 Single + Anteroom
Multi-State
Value
2
Devices Controlled
1 None
2 Exhaust
3 Exhaust / Supply / Temp
Multi-State
Value
3
Passcode Enable
Y
1 No Password
2 Room Mode Password
3 Menu Password
4 Menu & Room Mode
Passwords
Multi-State
Value
4
Input 1
Configuration
1 TSI Sensor
2 Pressure Transducer
Multi-State
Value
5
Input 2
Configuration
1 TSI Sensor
2 Pressure Transducer
3 Temperature Setpoint
4 None
Multi-State
Value
6
Input 3
Configuration
1 Supply Pressure Flow
2 Supply Linear Flow
3 Supply Venturi Flow
4 Supply Switch
7 None
Multi-State
Value
7
Input 4
Configuration
1 Room 1 Door Switch
2 Room 1 Occupancy
Sensor
3 None
Multi-State
Value
8
Input 5
Configuration
1 Room 1 Key Switch
2 Relative Humidity
3 None
Multi-State
Value
9
Input 6
Configuration
1 Room 1 Temp Sensor
2 Anteroom Occupancy
Sensor
5 Anteroom Door Switch
6 None
Multi-State
Value
10
Input 7
Configuration
1 Room 1 Supply Air Temp
2 Exhaust Pressure Flow
3 Exhaust Linear Flow
4 Exhaust Venturi Flow
5 Exhaust Switch
7 Anteroom Key Switch
8 None
