Room 1 Positive
Low Alarm
The Pos Low Alm item sets the positive low pressure
alarm setpoint. A low alarm condition is defined as when
the room is less positive than the Pos Low Alm setpoint.
This item is active when the TSI key switch is in positive
room pressure position or when POSITIVE is selected in
Room Mode item. However, it is always accessible
through the menu system.
-0.19500 in. W.C. to
+0.19500 in. W.C.
(TSI SENSOR)
-1.0 in W.C. to
+1.0 in W.C.
(PRESSURE
TRANSDUCER)
Pos Low Alm
cannot be set more
positive than the
Pos Setpnt
Room 1 Positive
High Alarm
The Pos Hi Alm item sets the positive high pressure
alarm setpoint. A high alarm condition is defined as when
the magnitude of the room pressure rises above the Pos
Hi Alm setpoint.
This item is active when the TSI key switch is in positive
room pressure position or when POSITIVE is selected in
Room Mode item. However, it is always accessible
through the menu system.
-0.19500 in. W.C. to
+0.19500 in. W.C.
(TSI SENSOR)
-1.0 in W.C. to
+1.0 in W.C.
(PRESSURE
TRANSDUCER)
Pos Hi Alm cannot
be set less positive
than the
Pos Setpnt
Room 1 Low
Exhaust Flow
Alarm
The Exh Low Alm item sets the minimum exhaust flow
alarm setpoint. A minimum flow alarm is defined as when
the exhaust flow is less than the Exh Low Alm setpoint.
Exh Low Alm
cannot be set
greater than the
Min Exh Flow
