TSI Instruments PRESSURA RPC30 User Manual

24
Part Two
Room1 Alarm Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT VALUE
Room 1 Low
Supply Flow Alarm
Sup Low Alm
The Sup Low Alm item sets the minimum supply flow
alarm setpoint. A minimum flow alarm is defined as when
the supply flow is less than the Sup Low Alm setpoint.
0 to 30,000 cfm
NOTE
Sup Low Alm
cannot be set
greater than the
Min Sup Flow
0 cfm
Room 1 Low Room
Temperature Alarm
Temp Low
Alm
The Temp Low Alm item sets the minimum room
temperature alarm setpoint.
50 to 100°F
NOTE
Temp Low Alm
cannot be set
greater than the
Temp Hi Alm
50 °F
High Room
Temperature Alarm
Temp Hi Alm
The Temp Hi Alm item sets the maximum room
temperature alarm setpoint.
50 to 100°F
NOTE
Temp Hi Alm
cannot be set less
than the
Temp Low Alm
100°F
Low Relative
Humidity Alarm
RH Low Alm
The RH Low Alm item sets the minimum relative humidity
alarm setpoint.
0 to 100%
NOTE
RH Low Alm
cannot be set
greater than the
RH Hi Alm
0%
High Relative
Humidity Alarm
RH Hi Alm
The RH Hi Alm item sets the maximum relative humidity
alarm setpoint.
0 to 100%
NOTE
RH Hi Alm cannot
be set less than
the RH Low Alm
100%
