TSI Instruments PRESSURA RPC30 User Manual

30
Part Two
Rm1 Setpnts Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Room 1 No
Isolation Mode
Control
No Iso Type
The No Iso Type item sets the method of control when
the PresSura controller is in NO ISOLATION mode.
If this item is set to:
FLOW The PresSura controller will maintain an
exhaust flow rate when in NO ISOLATION
mode.
POSITION The PresSura controller will maintain the
exhaust at a set damper position when in
NO ISOLATION mode.
PRESSURE The PresSura controller will continue to
modulate the exhaust in order to maintain
the room pressure differential setpoint, but
pressure alarms are inactive.
Flow
Position
Pressure
Position
Room 1 No
Isolation Mode
Setpoint
No Iso Setpnt
The No Iso Setpnt item sets the setpoint when the
PresSura controller is in NO ISOLATION mode and the
No Iso Type item is set to FLOW, POSITION or
PRESSURE.
NOTE: If No Iso Type is set to PRESSURE, then the
RPC30 will use the Neg Setpnt or Pos Setpnt.
0 to 30,000 CFM
0 to 100%
0%
Room 1 Minimum
Temperature for
Heating – Normal
Mode
Temp Heat
The Temp Heat item is the temperature at which the
heating valve is expected to be fully open. The throttling
range of the heating valve is the Temp Cool –
Temp Heat.
55 to 85°F
68°F
NOTE: The difference between the Temp Heat and Temp
Cool items must be between 1°F and 20°F.
Room 1 Maximum
Temperature for
Cooling – Normal
Mode
Temp Cool
The Temp Cool item is the temperature at which the
heating valve is expected to be fully closed. The throttling
range of the heating valve is the Temp Cool –
Temp Heat.
55 to 85°F
73°F
NOTE: The difference between the Temp Heat and Temp
Cool items must be between 1°F and 20°F.
