Rm1 Setpnts Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Room 1 Minimum
Temperature for
Heating –
Unoccupied Mode
Unoc Heat
The Unoc Heat item is the temperature at which the
heating valve is expected to be fully open. The throttling
range of the heating valve is the Unoc Cool – Unoc Heat.
55 to 85°F
65°F
NOTE: The difference between the Unoc Heat and Unoc
Cool items must be between 1°F and 20°F.
Room 1 Maximum
Temperature for
Cooling –
Unoccupied Mode
Unoc Cool
The Unoc Cool item is the temperature at which the
heating valve is expected to be fully closed. The throttling
range of the heating valve is the Unoc Cool – Unoc Heat.
55 to 85°F
75°F
NOTE: The difference between the Unoc Heat and Unoc
Cool items must be between 1°F and 20°F.
Room 1 Maximum
Supply Air
Temperature
Sup Temp Diff
The Sup Temp Diff item sets the maximum difference
between the supply air and room air temperature when
heating.
10°F to 40°F
20°F
NOTE: Input7 must be configured to ROOM1 SUPPLY
AIR TEMP SENSOR for this item to active.
Room 1 Minimum
Supply Flow Rate
Min Sup Flow
The Min Sup Flow item sets the minimum supply flow in
Occupied mode.
0 to 10,000 CFM
NOTE
Min Sup Flow
cannot be set
greater than the
Max Sup Flow
0 CFM
NOTE: Input3 must be configured to measure supply flow
for this item to be active.
If Min Sup Flow is programmed to be higher than
Heat Flow or Cool Flow, Heat Flow or Cool
Flow will be reset to the Min Sup Flow setpoint.
Room1 Maximum
Supply Flow Rate
Max Sup Flow
The Max Sup Flow item sets the maximum supply flow.
0 to 10,000 CFM
NOTE
Max Sup Flow
cannot be set less
than the
Min Sup Flow
10,000 CFM
NOTE: Input3 must be configured to measure supply flow
for this item to be configured.
